Parallax.js
Simple, lightweight Parallax Engine that reacts to the orientation of a smart device. Where no gyroscope or motion detection hardware is available, the position of the cursor is used instead.
Setup
Simply create a list of elements giving each item that you want to move within your parallax scene a class of layer and a data-depth attribute specifying its depth within the scene. A depth of 0 will cause the layer to remain stationary, and a depth of 1 will cause the layer to move by the total effect of the calculated motion. Values inbetween 0 and 1 will cause the layer to move by an amount relative to the supplied ratio.
<ul id="scene"> <li class="layer" data-depth="0.00"><img src="layer1.png"></li> <li class="layer" data-depth="0.20"><img src="layer2.png"></li> <li class="layer" data-depth="0.40"><img src="layer3.png"></li> <li class="layer" data-depth="0.60"><img src="layer4.png"></li> <li class="layer" data-depth="0.80"><img src="layer5.png"></li> <li class="layer" data-depth="1.00"><img src="layer6.png"></li> </ul>
To kickoff a Parallax scene, simply select your parent DOM Element and pass it to the Parallax constructor.
var scene = document.getElementById('scene');
var parallax = new Parallax(scene);
Behaviours
There are a number of behaviours that you can setup for any given Parallax instance. These behaviours can either be specified in the markup via data attributes or in JavaScript via the constructor and API.
| Behaviour | Values | Description |
|---|---|---|
| calibrate-x | true or false | Specifies whether or not to cache & calculate the motion relative to the initial x axis value on initialisation. |
| calibrate-y | true or false | Specifies whether or not to cache & calculate the motion relative to the initial y axis value on initialisation. |
| invert-x | true or false | true moves layers in opposition to the device motion, false slides them away. |
| invert-y | true or false | true moves layers in opposition to the device motion, false slides them away. |
| limit-x | number or false | A numeric value limits the total range of motion in x, false allows layers to move with complete freedom. |
| limit-y | number or false | A numeric value limits the total range of motion in y, false allows layers to move with complete freedom. |
| scalar-x | number | Multiplies the input motion by this value, increasing or decreasing the sensitivity of the layer motion. |
| scalar-y | number | Multiplies the input motion by this value, increasing or decreasing the sensitivity of the layer motion. |
| friction-x | number 0 - 1 | The amount of friction the layers experience. This essentially adds some easing to the layer motion. |
| friction-y | number 0 - 1 | The amount of friction the layers experience. This essentially adds some easing to the layer motion. |
In addition to the behaviours described above, there are two methods enable() and disable() that activateand deactivate the Parallax instance respectively.
Behaviours: Data Attributes Example
<ul id="scene" data-calibrate-x="false" data-calibrate-y="true" data-invert-x="false" data-invert-y="true" data-limit-x="false" data-limit-y="10" data-scalar-x="2" data-scalar-y="8" data-friction-x="0.2" data-friction-y="0.8"> <li class="layer" data-depth="0.00"><img src="graphics/layer1.png"></li> <li class="layer" data-depth="0.20"><img src="graphics/layer2.png"></li> <li class="layer" data-depth="0.40"><img src="graphics/layer3.png"></li> <li class="layer" data-depth="0.60"><img src="graphics/layer4.png"></li> <li class="layer" data-depth="0.80"><img src="graphics/layer5.png"></li> <li class="layer" data-depth="1.00"><img src="graphics/layer6.png"></li> </ul>
Behaviours: Constructor Object Example
var scene = document.getElementById('scene');
var parallax = new Parallax(scene, {
calibrateX: false,
calibrateY: true,
invertX: false,
invertY: true,
limitX: false,
limitY: 10,
scalarX: 2,
scalarY: 8,
frictionX: 0.2,
frictionY: 0.8
});
Behaviours: API Example
var scene = document.getElementById('scene');
var parallax = new Parallax(scene);
parallax.enable();
parallax.disable();
parallax.calibrate(false, true);
parallax.invert(false, true);
parallax.limit(false, 10);
parallax.scalar(2, 8);
parallax.friction(0.2, 0.8);
jQuery
If you're using jQuery or Zepto and would prefer to use Parallax.js as a plugin, you're in luck!
$('#scene').parallax();
jQuery: Passing Options
$('#scene').parallax({
calibrateX: false,
calibrateY: true,
invertX: false,
invertY: true,
limitX: false,
limitY: 10,
scalarX: 2,
scalarY: 8,
frictionX: 0.2,
frictionY: 0.8
});
jQuery: API
var $scene = $('#scene').parallax();
$scene.parallax('enable');
$scene.parallax('disable');
$scene.parallax('calibrate', false, true);
$scene.parallax('invert', false, true);
$scene.parallax('limit', false, 10);
$scene.parallax('scalar', 2, 8);
$scene.parallax('friction', 0.2, 0.8);
iOS
If you are writing a native iOS application and would like to use parallax.js within a UIWebView, you will need to do a little bit of work to get it running.
UIWebView no longer automatically receives the deviceorientation event, so your native application must intercept the events from the gyroscope and reroute them to the UIWebView:
- Include the CoreMotion framework #import <CoreMotion/CoreMotion.h> and create a reference to theUIWebView @property(nonatomic, strong) IBOutlet UIWebView *parallaxWebView;
- Add a property to the app delegate (or controller that will own the UIWebView) @property(nonatomic, strong) CMMotionManager *motionManager;
- Finally, make the following calls:
self.motionManager = [[CMMotionManager alloc] init];
if (self.motionManager.isGyroAvailable && !self.motionManager.isGyroActive) {
[self.motionManager setGyroUpdateInterval:0.5f]; // Set the event update frequency (in seconds)
[self.motionManager startGyroUpdatesToQueue:NSOperationQueue.mainQueue
withHandler:^(CMGyroData *gyroData, NSError *error) {
NSString *js = [NSString stringWithFormat:@"parallax.onDeviceOrientation({beta:%f, gamma:%f})", gyroData.rotationRate.x, gyroData.rotationRate.y];
[self.parallaxWebView stringByEvaluatingJavaScriptFromString:js];
}];
}
